12G-SDI to Quad Link 3G-SDI Bi-Directional Converter
This product is discontinued
This product is discontinued. It has been replaced by the CQS 1462.
The CQS 1441 is a compact solution designed to bridge Quad Link 3G-SDI to Single Link 12G-SDI devices with support for 2SI only. This device does not support SQD.
Conversion modes include:
- 12G-SDI to 4x 3G-SDI (Quad Link 2SI)
- 6G-SDI to 4x 1.5G-SDI (Quad Link 2SI)
- 4x 3G-SDI (Quad Link 2SI) to 12G-SDI
- 4x 1.5G-SDI (Quad Link 2SI) to 6G-SDI
The module is suitable for all SMPTE standards ranging from 1.5G-SDI to 12G-SDI (SMPTE 292M, 424M, 2081 and 2082).
The 12G-SDI SFP cage offer optional fiber connectivity for both CWDM and non-CWDM variants.
The module is fully compatible with yelloGUI and LynxCentraal. It can be configured, controlled and updated using Windows or MacOS.
Key Features
Support 12G/6G/3G/1.5G-SDI Standards
Single to Quad 2SI Link and Quad 2SI to Single Link
SFP to BNC 1x5 Distribution Mode
BNC 1x4 Distribution Mode + Loop and SFP Out
Automatic Link Loss Reply Options for 2SI
ideo Formats
• UHD 3840x2160p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 • HD 1920x1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 • HD 1920x1080i -- -- -- -- -- -- -- 50, 59.94, 60
Video Input Digital
- 1x 12G-SDI BNC (12G/6G/3G/1.5G-SDI)
- 3x 3G-SDI BNC (3G/1.5G-SDI)
- YCbCr 4:2:2
- 10-bit
- 3G-SDI Level A or B Dual Link
- UHD Quad Link 2SI
Video Output Digital
- 2x 12G-SDI BNC (12G/6G/3G/1.5G-SDI)
- 3x 3G-SDI BNC (3G/1.5G-SDI)
- YCbCr 4:2:2
- 10-bit
- 3G-SDI Level A or B Dual Link
- UHD Quad Link 2SI
Fiber I/O
- 12G-SDI
- Simplex or Duplex Single-mode
- LC/ST/SC Connection
